| System |
Processors: Intel® Core™ i5-1135G7 Processor 8M Cache, up to 4.20 GHz |
| Intel® Core™ i3-1115G4 Processor 6M Cache, up to 4.10 GHz |
| Chipset: Intel® Tiger Lake |
| Memory: 4GB Standard, DDR4 3200 MT/s, Socket 1 x SODIMM (Max. 32GB) |
| Storage: SATA 3 (6Gb/s) 2.5 inch SSD 64GB, Support AHCI |
| RAID: RAID 0,1 |
| Operating Systems: Windows 10 IoT Enterprise |
| Audio: HD Audio Codec |
| Display |
Type: 15″ TFT LCD, LED Backlight |
| Resolution: 1024×768 |
| Brightness: 300 cd/ m2 (typ.) |
| Touchscreen: Projective Capacitive Touch |
| Interface |
Display: VGA x 1 (With Power Output) |
| USB: 6 (Rear 2, Back 4, USB 3.0 x 2, USB 2.0 x 2) |
| 3 (Reserved for MSR, SCR, i-Button/Touch Controller/Camera), RJ-45 |
| Serial: 6 (COM 1 with 5V/12V Power Output on 9 Pins, BIOS) |
| (COM2~3 RJ-45 , Full Signal) |
| (COM4 RJ-11, Only TX/RX, 12V Power Output, Reserved for CDP) |
| (COM5, Full Signal) |
| (COM6 RJ-45, Only TX/RX, 5V Power Output, Reserved for MSR) |
| Back I/O: Cash Drawer Port(GPIO Communication) (RJ-11 6 Pins) x 1 + USB 2.0 x 2 (Default) |
| Optional I/O: |
| Gigabit Ethernet x 1 (RJ-45) + USB 2.0 x 2 (Factory option) |
| 12V Powered USB 2.0 x 1 + 24V Powered USB 2.0 x 1 (Factory option) |
| 12V Powered USB 2.0 x 1 + 12V Powered USB 2.0 x 1 (Factory option) |
| 24V Powered USB 2.0 x 1 + 24V Powered USB 2.0 x 1 (Factory option) |
| 12V Powered USB 2.0 x 1 + USB 2.0 x 1 (Factory option) |
| 24V Powered USB 2.0 x 1 + USB 2.0 x 1 (Factory option) |
| COM5 x 1 (RJ-45 , Full signal) + USB 2.0 x 2 (Factory option) |
| USB A 2.0 x 4 (Factory option) |
| One option attachable at a time |
| LAN: Gigabit Ethernet x 1 (RJ-45) |
| Audio: Line-out x 1 |
| Power DC-IN: 3 Pin DIN Jack |
| Extension Shot: M.2 for WiFi/BT, SSD |
| Power |
Power Supply: Adapter 24V, 2.5A (Nomarl) / 24V, 6.35A(Powered USB Option) |
| Physical & Environmental |
Operating Temperature: 0 °C ~ 50 °C at 10% to 90% Humidity |
| Storage Temperature: -20 °C ~ 80 °C at 10% to 90% Humidity |
| Dimensions (W x H x D): 364 x 333 x 210 (mm), 14.3 x 13.1 x 8.2(in) |
| Packing Dimensions (W x H x D): 500 x 470 x 300 (mm), 19.6 x 18.5 x 11.8(in) |
| Net Weight: 5,300g, 11.68 lbs |
| Packing Weight: 8,000g, 17.63 lbs |
| Color: Dark Grey, High Gloss White |
| Options & Peripherals |
2nd Displays: 9.7″, 12.1″, 15″ LCD Display, 1024 x 768, Optional Touchscreen |
| Customer Display: VFD, 20 Columns x 2 Lines |
| Storage: 2.5 inch SSD 128GB, HDD 500GB, 1TB |
| Magnetic Stripe Reader: Comply with ISO 7811, Support 1 & 2 & 3 Track |
| Smart Card Reader: EMV Level 1 |
| Dallas: Dallas i-button Reader |
| Fingerprint: Yes |
| Wall Mount Kit: VESA-Compatible, 75 x 75(mm), 100 x 100(mm) |
| Serial Conversion Cable: RJ-45 to D-sub 9 |
| Speaker: 2 x 1W (Stereo) (Factory Option) |
| WiFi/BT: M.2 for WiFi/BT |
| TPM: Support |
