Description
| Light Source | White LED |
| Module | 2D imager 1280*960 |
| Code Range | 1D, 2D DPM, Monitor-displayed |
| Angle | Skew ±60˚, pitch ±65˚, roll ±42˚ |
| Memory | 1M byte |
| Distance | 500 meters |
| Alert Mode | Indicator & buzzer |
| Interface | USB, RS232, USB-COM |
| Trigger Mode | Manual, continuous scanning, auto-detective |
| Mode Setting | Set by scanning functional barcodes or cradle key |
| Barcode | 1D & 2D |
| Input Voltage | 5V DC, ±0.25V |
| DC Current | 270mA |
